Introduction

If you work with fMRI data, you already know the core analysis is multiple regression applied voxel-by-voxel — but specifying the design matrix, convolving events with hemodynamic response functions, and managing multi-run structures can be tedious and error-prone.

The fmrireg package gives you a concise, formula-based interface for these tasks, inspired by lm() and glm(). You describe your experimental design and HRF choices in a formula, and fmrireg handles convolution, baseline modeling, contrast computation, and model fitting.

This vignette starts with a complete, small fit and then unpacks the objects behind it. You begin with a time-by-voxel matrix and an event table; you finish with one coefficient estimate per condition and voxel.

A complete fit first

For a compact example, we create two voxels with different known responses to faces and scenes. In your own analysis, bold would be the matrix extracted from preprocessed images or regions of interest.

quick_events <- data.frame(
  onset = seq(10, 80, by = 10),
  condition = factor(rep(c("face", "scene"), 4)),
  run = 1L
)
quick_frame <- sampling_frame(blocklens = 80, TR = 2)
quick_event_model <- event_model(
  onset ~ hrf(condition), block = ~ run,
  data = quick_events, sampling_frame = quick_frame
)
quick_design <- as.matrix(design_matrix(quick_event_model))
quick_truth <- matrix(
  c(1.0, 0.6, 0.7, 1.1), nrow = ncol(quick_design),
  dimnames = list(colnames(quick_design), c("voxel1", "voxel2"))
)
set.seed(2026)
bold <- quick_design %*% quick_truth + matrix(rnorm(80 * 2, sd = 0.2), 80, 2)
quick_dataset <- matrix_dataset(
  bold, TR = 2, run_length = 80, event_table = quick_events
)
face_vs_scene <- pair_contrast(
  ~ condition == "face", ~ condition == "scene",
  name = "face_vs_scene"
)
fit <- fmri_lm(
  onset ~ hrf(condition, contrasts = face_vs_scene), block = ~ run,
  dataset = quick_dataset
)

coefficient_table <- data.frame(
  condition = levels(quick_events$condition),
  truth_voxel1 = quick_truth[, 1],
  estimate_voxel1 = as.numeric(coef(fit)[1, ]),
  truth_voxel2 = quick_truth[, 2],
  estimate_voxel2 = as.numeric(coef(fit)[2, ])
)
knitr::kable(coefficient_table, digits = 2,
             row.names = FALSE,
             caption = "Known and recovered condition effects")
Known and recovered condition effects
condition truth_voxel1 estimate_voxel1 truth_voxel2 estimate_voxel2
face 1.0 0.95 0.7 0.51
scene 0.6 0.76 1.1 1.14

quick_contrast_numeric <- data.frame(
  voxel = colnames(quick_truth),
  estimate = as.numeric(coef(fit, type = "contrasts")$face_vs_scene),
  std_error = as.numeric(standard_error(fit, type = "contrasts")$face_vs_scene),
  statistic = as.numeric(stats(fit, type = "contrasts")$face_vs_scene),
  p_value = as.numeric(p_values(fit, type = "contrasts")$face_vs_scene)
)
quick_contrast <- transform(
  quick_contrast_numeric,
  p_value = format.pval(p_value, digits = 3, eps = 1e-4)
)
knitr::kable(quick_contrast, digits = 3,
             row.names = FALSE,
             caption = "Face-minus-scene contrast with uncertainty")
Face-minus-scene contrast with uncertainty
voxel estimate std_error statistic p_value
voxel1 0.440 0.053 8.319 <1e-04
voxel2 -0.379 0.062 -6.116 <1e-04

The first table separates the known effect sizes from their estimates. The second table asks a scientific question—face minus scene—and reports its estimate, standard error, test statistic, and p-value for each voxel. Here the first voxel favors faces while the second favors scenes, recovering the pattern used to generate the data. The next sections unpack the dataset, event, baseline, and contrast objects used for larger analyses.

Key Components and Workflow

A typical fMRI analysis workflow with fmrireg involves these main stages:

  1. Data Representation: Defining how your fMRI data and experimental design are organized.
  2. Model Building: Specifying the regression model using formulas, including:
    • Defining Hemodynamic Response Functions (HRFs).
    • Creating event-related regressors (event_model).
    • Modeling baseline components like drift and nuisance factors (baseline_model).
    • Defining contrasts of interest (contrast).
  3. Model Estimation: Fitting the specified model to the data (e.g., using fmri_lm).
  4. Advanced Topics: Exploring single-trial estimation, simulation, group analysis, or accelerated engines.

1. Data Representation

Before modeling, you need to represent your fMRI data and its structure. fmrireg uses objects like:

  • fmri_dataset / fmri_mem_dataset: Encapsulates the 4D fMRI data (potentially file-backed or in-memory), mask information, TR, run structure, and the experimental design table.
  • sampling_frame: Defines the temporal structure – the number of scans per run (blocklens) and the repetition time (TR).
# Example: one run, 120 scans, TR=2s
sframe <- sampling_frame(blocklens = 120, TR = 2)
sframe
#> Sampling frame
#> - Blocks: 1
#> - Scans: 120 (per block: 120 )
#> - TR: 2 s
#> - Duration: 239 s

2. Model Building

a) Hemodynamic Response Function (HRF)

The HRF models the BOLD signal response to a brief neural event. fmrireg provides various pre-defined HRFs (e.g., HRF_SPMG1, HRF_GAUSSIAN) and functions to create or modify them (gen_hrf, hrf_blocked, hrf_lagged).

# Plot the SPM canonical HRF
time <- seq(0, 24, by = 0.2)
plot(time, HRF_SPMG1(time), type = 'l', xlab = "Time (s)", ylab = "BOLD Response",
     main = "SPM Canonical HRF (HRF_SPMG1)")

Line plot of the SPM Canonical HRF (BOLD response over time in seconds)

  • Related Topic: Hemodynamic Response Functions

b) Event Model (event_model)

This defines the task-related part of your GLM. You specify how experimental events (onsets, conditions, durations) map to regressors using a formula syntax. The hrf() or afni_hrf() functions within the formula link event variables to specific HRF shapes.

# A simple design table with two stimulus types
design_table <- data.frame(
  onset = c(10, 40, 70, 100, 130, 160, 190, 220),
  stim_type = factor(rep(c("face", "scene"), 4)),
  run_id = rep(1, 8)
)
# Model the effect of stim_type, convolved with the SPM canonical HRF
event_mod <- event_model(onset ~ hrf(stim_type),
                         data = design_table,
                         block = ~ run_id,
                         sampling_frame = sframe)
event_mod
  • Related Topic: Event Models

c) Baseline Model (baseline_model)

This models non-task-related components like scanner drift, run intercepts, and other nuisance factors (e.g., motion parameters).

# Example: Cubic B-spline drift model + run intercepts
# (Requires 'sframe' defined earlier)
base_mod <- baseline_model(basis = "bs", degree = 3, sframe = sframe)
print(base_mod)
#> ================================================
#>            Baseline Model
#> ================================================
#>   Drift Components
#>     * Name: baseline_bs_3
#>     * Basis type: bs
#>     * Degree: 3
#>     * Drift columns: 3
#>
#>   Additional Components
#>     * Constant columns: 1
#>     * Nuisance columns: 0
#>
#>   Model Summary
#>     * Total columns: 4
#>
#>   Design Matrix Preview
#>      0.000  0.000  0.000  1.000
#>      0.025  0.000  0.000  1.000
#>      0.049  0.001  0.000  1.000
#> ================================================
  • Related Topic: Baseline Models

d) Contrasts (pair_contrast, unit_contrast, etc.)

Contrasts define specific comparisons between condition estimates.

# Example: Contrast comparing 'face' vs 'scene' levels of 'stim_type'
face_vs_scene <- pair_contrast(~ stim_type == "face", ~ stim_type == "scene", name = "FvS")
print(face_vs_scene)
#> contrast: FvS
#>  A:  ~stim_type == "face"
#>  B:  ~stim_type == "scene"

3. Model Estimation (fmri_model, fmri_lm)

You combine the event and baseline models into a full fmri_model and then fit it to your fmri_dataset using estimation functions like fmri_lm (for standard GLM) or estimate_betas (for single-trial betas).

# Create three example voxel series over the same one-run design
set.seed(42)
overview_data <- matrix_dataset(
  matrix(rnorm(120 * 3), 120, 3),
  TR = 2, run_length = 120, event_table = design_table
)

# Combine the design with its dataset, then fit it
full_model <- fmri_model(event_mod, base_mod, dataset = overview_data)
overview_fit <- fmri_lm(full_model)
overview_coef_matrix <- coef(overview_fit)
overview_coef_table <- data.frame(
  condition = levels(design_table$stim_type),
  voxel_1 = overview_coef_matrix[, 1],
  voxel_2 = overview_coef_matrix[, 2],
  voxel_3 = overview_coef_matrix[, 3],
  check.names = FALSE
)
knitr::kable(
  overview_coef_table, digits = 2, row.names = FALSE,
  caption = "Condition coefficients from the object-building route"
)
Condition coefficients from the object-building route
condition voxel_1 voxel_2 voxel_3
face -0.09 -0.14 -0.11
scene 0.05 0.06 0.10

This second fit uses the object-building route rather than the compact formula route shown first. See the linear-model vignette for AR prewhitening, robust row weighting, uncertainty estimates, and model diagnostics.

4. Advanced Topics

fmrireg also supports:

Acceleration: Sketched / Nyström Analysis

For large problems, you can accelerate voxelwise GLM estimation with: - SRHT/IHS temporal sketching to reduce timepoints while preserving LS geometry. - Nyström/landmark spatial extension to solve on a subset of voxels and extend with parcel‑aware kernels.

See vignette("sketched-ar", package = "fmrireg") for guidance, tradeoffs, and practical defaults.

Group-Level Meta-Analysis

Combine subject‑level maps or ROI summaries using fixed/random‑effects meta‑regression: - Inputs: HDF5/NIfTI (beta+SE or t+df) or ROI CSV. - Random‑effects: Paule–Mandel/DerSimonian–Laird/REML alias; optional robust Huber. - t‑only combine: Stouffer/Fisher/Lancaster (supports equal/IVW/custom weights where applicable). - Exact contrasts: at fit‑time (contrasts=…) or post‑hoc via return_cov = "tri" + contrast(). - Multiple comparisons: BH FDR or spatial FDR (block/parcel aware).

See vignette("group_analysis", package = "fmrireg") for end‑to‑end examples.

Getting Started

This overview provides a map of the fmrireg package. For detailed explanations and examples, please refer to the specific vignettes linked above.
