Fit a whole-brain pattern model • rMVPA

A pattern model answers a joint question: can the whole feature domain decode the task, and where is that information expressed? It fits one low-rank forward model

$x = A C^{\top} y + \varepsilon, \qquad \varepsilon \sim (0, \Psi)$

and then reuses that fit for classification or multivariate decoding, encoding, forward patterns, and restricted regional prediction. You do not fit one model to predict labels and another to draw a map.

This is the first of three pattern-model articles. Confirmation of a frozen fit is vignette("Pattern_Confirmation"); pooling confirmed subject loadings is vignette("Pattern_Group").

When to use it

Use pattern_model() when you want one covariance-aware fit over a whole domain (or a large ROI) and several derived answers from it:

held-out classification or multi-response decoding
model-implied forward patterns, not only decoding weights
how much of the whole-domain prediction remains accessible inside a region
later confirmation or group analysis of those patterns

Use a different family when the question is narrower:

Question	Model family
Decode feature vectors inside independently fitted regions	`feature_rsa_model` (`vignette("Feature_RSA")`)
Voxelwise encoding from grouped predictors	`banded_ridge_model` (`vignette("Banded_Ridge_Encoding")`)
Map between perception and retrieval domains	`remap_rrr_model` (`vignette("REMAP_RRR")`)
Find locally predictive neighborhoods with separate local fits	searchlight analysis (`vignette("Searchlight_Analysis")`)

The current residual covariance is diagonal plus a few shared noise components. It can miss richer local noise correlations. Spatial penalties act on the forward patterns $A$ , not on decoding weights.

What you pass in and get back

Object	Role
`mvpa_dataset`	Brain measurements. Rows are observations; columns are features.
design with `model_targets()`	Categorical labels (`mvpa_design`) or a numeric target matrix (`targets`, `feature_sets_design`, or `feature_rsa_design`).
`pattern_model()`	The specification: rank, noise, optional spatial penalty, optional observation weights.
`run_global()`	One domain-wide evaluation. Same specification also works with `run_regional()` and `run_searchlight()`.
`pattern_global_result`	Held-out `performance_table`, prediction ledger, optional fold fits, optional full-data `refit`.

The usual next calls on that result are performance(), model_importance() / model_patterns() on $refit, local_performance(), and predict() on a retained pattern_fit.

Plant four territories

The example has 120 observations in three runs and 48 voxels. Class labels cycle through a, b, and c. Four contiguous territories are planted:

signal 1 (voxels 1–12): an A-versus-B code, plus a shared noise process
signal 2 (voxels 13–24): a B-versus-C code
shared noise (voxels 25–36): the same noise process, no task loading
background (voxels 37–48): independent noise only

The shared-noise territory is a noise canceller. Observing it can improve whole-domain decoding even when its forward loading is near zero. That is why the guide keeps forward patterns and decoding weights as separate outputs.

n <- 120
p <- 48
class <- factor(rep(c("a", "b", "c"), length.out = n))
run <- rep(1:3, each = 40)
code <- model.matrix(~ class - 1)
X <- matrix(rnorm(n * p), n, p)
shared_noise <- rnorm(n, sd = 2)
X[, 1:12]  <- X[, 1:12]  + 1.2 * (code[, 1] - code[, 2]) + shared_noise
X[, 13:24] <- X[, 13:24] + 1.2 * (code[, 2] - code[, 3])
X[, 25:36] <- X[, 25:36] + shared_noise

space <- neuroim2::NeuroSpace(c(4, 4, 3), c(1, 1, 1))
mask <- neuroim2::NeuroVol(array(1, c(4, 4, 3)), space)
images <- neuroim2::NeuroVec(
  array(t(X), c(4, 4, 3, n)),
  neuroim2::NeuroSpace(c(4, 4, 3, n), c(1, 1, 1))
)
dataset <- mvpa_dataset(images, mask = mask)
design <- mvpa_design(data.frame(class, run), y_train = ~ class,
                      block_var = ~ run)

Fit the domain and score held-out runs

spec <- pattern_model(dataset, design, rank = 2,
                      noise = list(type = "diag_lowrank", rank = 1))
result <- run_global(spec, return_fits = TRUE, refit = TRUE)
performance(result)
#> # A tibble: 1 × 4
#>   Accuracy   AUC logloss rank_mean
#>      <dbl> <dbl>   <dbl>     <dbl>
#> 1    0.983 0.998  0.0532         2

performance() is leave-one-run-out accuracy. Chance is one third. rank_mean is the mean rank selected across outer folds; here rank is fixed at 2, so the column is exactly 2.

Two fits are retained for different jobs:

fold fits (return_fits = TRUE) are the cross-validated estimators. local_performance() and the Haufe diagnostic need them.
$refit uses every training row. It is the descriptive map and the object you would confirm later. It is not the fit that produced the accuracy table.

return_fits = TRUE costs memory, especially with many resamples.

X_all <- get_feature_matrix(dataset)
head(predict(result$refit, X_all, type = "prob"))
#>                 a            b            c
#> [1,] 9.965573e-01 7.158840e-14 3.442679e-03
#> [2,] 4.620917e-13 1.000000e+00 1.289233e-16
#> [3,] 2.736966e-05 1.686358e-10 9.999726e-01
#> [4,] 9.999999e-01 6.327767e-12 1.367196e-07
#> [5,] 1.725962e-11 1.000000e+00 3.411714e-13
#> [6,] 4.256850e-05 2.393210e-18 9.999574e-01

predict() on a pattern_fit returns class probabilities, class labels, decoded continuous targets, calibrated scores, or encoded brain measurements. The probabilities above come from the descriptive refit, so they are not the held-out scores in performance().

Read where the signal lives

signal_sd <- model_importance(result$refit, type = "signal_sd")
information <- model_importance(result$refit, type = "conditional_info")
oldpar <- par(mfrow = c(1, 2), mar = c(4, 4, 2, 1))
for (panel in list(
  list(y = signal_sd, ylab = "Signal SD"),
  list(y = information, ylab = "Conditional information (nats)")
)) {
  plot(panel$y, type = "h", xlab = "Input voxel", ylab = panel$ylab)
  abline(v = c(12.5, 24.5, 36.5), lty = 2, col = "grey70")
  mtext(c("S1", "S2", "noise", "bg"), side = 3, line = 0,
        at = c(6, 18, 30, 42), cex = 0.8)
}

Model-implied signal standard deviation and Gaussian conditional information across 48 input voxels, with planted territory boundaries.

par(oldpar)

Signal SD is $\sqrt{\mathrm{diag}(A\Phi A')}$ in the original measurement units. It says where fitted task variance is expressed. In this realization the B-versus-C territory (S2) is strongest, the A-versus-B territory (S1) is next, and background is near zero. The shared-noise territory is not exactly zero: finite-sample loadings rarely vanish without a sparsity penalty.

Conditional information asks what a voxel adds once the other voxels have been observed. It can be high in a noise canceller whose signal SD is modest. It is a working Gaussian score-model quantity, in nats — not empirical mutual information about class labels, and not a significance map.

model_importance(result) builds a spatial image through the dataset. model_importance(result$refit) returns a vector aligned to input columns; screened columns are NA. Component-wise forward patterns and calibrated decoder weights come from model_patterns(fit, "forward") and model_patterns(fit, "weights"). Those columns depend on the chosen component coordinates. Scalar maps do not.

Ask what each region can decode

local_performance() keeps the whole-domain task representation and restricts only the residual covariance to the region. It then predicts the same held-out observations used for the whole-domain score. Cropping whole-brain decoding weights would keep noise-cancellation terms that require unobserved voxels; that is a different, generally incorrect, estimand.

regions <- list(
  signal_1     = 1:12,
  signal_2     = 13:24,
  shared_noise = 25:36,
  background   = 37:48,
  whole_domain = 1:48
)
local <- local_performance(result, regions)
local[local$metric == "Accuracy", ]
#>          region   metric whole_brain local_restricted
#> 1      signal_1 Accuracy   0.9833333        0.3250000
#> 4      signal_2 Accuracy   0.9833333        0.9750000
#> 7  shared_noise Accuracy   0.9833333        0.3916667
#> 10   background Accuracy   0.9833333        0.2916667
#> 13 whole_domain Accuracy   0.9833333        0.9833333

Each name in regions is a set of input-matrix column positions, not voxel IDs.

In this realization the table matches the planting:

signal 2 decodes well on its own.
signal 1 is near chance by itself. It carries both the A-versus-B code and the shared noise, and without the canceller it cannot separate them.
shared noise is also near chance alone, as it should be: it has no task loading.
whole domain recovers the high held-out accuracy. The canceller is useful only when the signal territories are observed with it.

The regional score is access under the shared whole-brain representation, not the best accuracy a separately trained local model could reach. A finite-sample region can beat the whole-domain number. For a true independent-ROI comparison, pass fold-resolved ledgers through independent_roi; those ledgers must match rows, folds, truth, and baselines.

Decode continuous feature targets

The same constructor accepts a numeric target matrix. The example below encodes two continuous features into the first two territories.

features <- matrix(rnorm(n * 2), n, 2,
                   dimnames = list(NULL, c("feature_1", "feature_2")))
brain <- matrix(rnorm(n * p), n, p)
brain[, 1:12]  <- brain[, 1:12]  + features[, 1]
brain[, 13:24] <- brain[, 13:24] + features[, 2]
continuous_data <- mvpa_dataset(
  neuroim2::NeuroVec(
    array(t(brain), c(4, 4, 3, n)),
    neuroim2::NeuroSpace(c(4, 4, 3, n), c(1, 1, 1))
  ),
  mask = mask
)
continuous_design <- mvpa_design(
  data.frame(id = 1:n, run),
  cv_labels = 1:n, targets = features, block_var = ~ run
)
continuous <- run_global(
  pattern_model(continuous_data, continuous_design, rank = 2),
  return_fits = TRUE
)
performance(continuous)
#> # A tibble: 1 × 4
#>      R2  RMSE   cor rank_mean
#>   <dbl> <dbl> <dbl>     <dbl>
#> 1 0.903 0.304 0.950         2
local_performance(continuous, list(first = 1:12, second = 13:24))
#>   region metric whole_brain local_restricted
#> 1  first     R2   0.9030424        0.4457892
#> 2  first   RMSE   0.3038478        0.6301593
#> 3  first    cor   0.9503506        0.5334221
#> 4 second     R2   0.9030424        0.3383942
#> 5 second   RMSE   0.3038478        0.7056156
#> 6 second    cor   0.9503506        0.4523845

R2 is predictive R-squared against each fold’s training-target mean, not squared correlation, and it can be negative. The reported value averages per-response R-squared. Targets are centred and whitened on training rows only; predict(..., type = "decode") returns original target units. Here each territory reconstructs its own feature only partly; the whole domain does much better because both features are observed together.

feature_sets_design is the other common continuous-target path. Its row_weights are used by the estimator (see below).

Control rank, penalties, and weights

Rank. "auto" (the default) selects rank inside each outer training split by held-out decoding loss, then reports rank_mean. A fixed integer is used as given and still capped at the eligible rank (number of classes minus one for categorical targets).

Spatial penalties act on $A$ . They are optional and they are hypotheses about anatomy, not defaults.

# Localized support: a feature is in the patterns or out of them.
pattern_model(dataset, design, rank = 2, penalty = list(sparse = 0.1))

# Neighbouring voxels should carry similar signed loadings.
# A spatial_graph() is built from the dataset when one is not supplied.
pattern_model(dataset, design, rank = 2, penalty = list(signed_smooth = 1))

sparse is a fraction of the penalty that empties the model, so 0.1 means the same thing across folds and domains. signed_smooth is the weight of a graph-Laplacian term relative to the data-fit curvature. Either entry may be "auto", which cross-validates a short path jointly with rank. Do not default to sparse = "auto" on a dense or weak whole-brain code: inner folds can pick a penalty that hurts held-out accuracy. Use sparsity when you believe support is localized. support_smooth is reserved for a later envelope penalty and is rejected rather than quietly remapped.

Observation weights enter the fit itself: centring, target whitening, the residual covariance, the objective, and the inner tuning loss. They do not reweight the reported metrics — every tested observation still counts once.

# Explicit weights override design-carried row_weights.
# A zero weight drops that row from training, exactly.
pattern_model(dataset, design, rank = 2, weights = w)

If the design is a feature_sets_design, its row_weights are used automatically. Integer weights are equivalent to replicating rows. Confirmation (vignette("Pattern_Confirmation")) does not accept nonuniform weights.

Rotate a display and compare folds

view <- rotate_patterns(result$refit)
view$reconstruction_error
#> [1] 1.272449e-15
result$component_stability[, c("fold1", "fold2", "rank1", "rank2",
                               "n_common", "overlap")]
#>   fold1 fold2 rank1 rank2 n_common   overlap
#> 1     1     2     2     2       48 0.9213209
#> 2     1     3     2     2       48 0.8117325
#> 3     2     3     2     2       48 0.7999901

rotate_patterns() changes display coordinates while preserving $L_b H L_t' = A C'$ . The underlying fit is unchanged, so predictions and scalar maps stay bit-identical. Only orthogonal rotations are supported. Compare patterns across folds or subjects with the column space, the support, or a coordinate-invariant map — never raw entries of $A$ .

component_stability compares spatial column spaces with principal angles on features retained in both folds. An overlap of one means the two nonempty subspaces coincide. Unequal ranks reduce overlap even if the smaller space sits inside the larger. This is a subspace diagnostic, not a test that a particular rank is supported.

vapply(result$haufe_diagnostics, function(x) x$relative_discrepancy,
       numeric(1))
#> [1] 0.4278746 0.5853670 0.7012616

The Haufe diagnostic compares empirical held-out covariance patterns with the model-implied patterns. Large discrepancies can flag sampling noise or misspecification; they are not p-values. Automatic results use train:<row ID> for training and CV rows and test:<row ID> for an external test partition. Independence of an external partition is a caller obligation. For a separately held-out matrix, call pattern_haufe(fit, X_holdout, observation_ids).

Save and continue

save_results(result, "pattern-output")

The RDS stores the result, including retained fits and ledgers. Spatial refit maps are also written as images for supported datasets. Multibasis image aggregation is refused because averaging channels would change the estimand; those results save as RDS.

To test the frozen discovery directions on new rows, continue with vignette("Pattern_Confirmation"). To pool confirmed subject loadings in a shared target basis, use vignette("Pattern_Group").
