Confirming a frozen pattern model • rMVPA

A discovery fit chooses directions worth studying. Confirmation asks whether those already chosen directions predict brain measurements in independent data. It estimates fresh, unpenalized loadings while freezing the target coding, whitening, and component directions learned during discovery.

This separation permits t and omnibus tests without treating a selected, regularized discovery loading as an ordinary regression coefficient. It does not turn cross-validated rank selection into a test of population rank.

Freeze a discovery fit

The example has two continuous targets and 32 features. The first half of the features responds to the first target; the second half responds to the second. Shared run noise makes rows within a run dependent.

p <- 32
A <- cbind(rep(c(1, 0), each = 16), rep(c(0, 1), each = 16))
make_sample <- function(n = 120, runs = 12) {
  Y <- cbind(speed = rnorm(n), difficulty = rnorm(n))
  run <- rep(seq_len(runs), length.out = n)
  X <- Y %*% t(A) + matrix(rnorm(n * p), n, p) + rnorm(runs)[run]
  list(X = X, Y = Y, run = run)
}
discovery <- make_sample(runs = 4)
space <- neuroim2::NeuroSpace(c(4, 4, 2), c(1, 1, 1))
mask <- neuroim2::NeuroVol(array(1, c(4, 4, 2)), space)
images <- neuroim2::NeuroVec(array(t(discovery$X), c(4, 4, 2, 120)),
                            neuroim2::NeuroSpace(c(4, 4, 2, 120), c(1, 1, 1)))
dataset <- mvpa_dataset(images, mask = mask)
design <- mvpa_design(data.frame(y = discovery$Y[, 1], run = discovery$run),
                      y_train = ~ y, block_var = ~ run, targets = discovery$Y)
fit <- run_global(pattern_model(dataset, design, rank = 2), refit = TRUE)$refit
basis <- pattern_basis(fit)
round(basis$matrix, 3)
#>              [,1]  [,2]
#> speed      -0.705 0.683
#> difficulty  0.712 0.670

The rows of basis$matrix are named raw targets and its columns are frozen scores. This matrix includes the training scaling and whitening; storing C alone would lose that information. Independent display rotations from rotate_patterns() do not redefine this inference basis.

Estimate and test loadings on new rows

Use globally meaningful observation IDs, including the participant, session, and observation identity in a real study. Declare every discovery row used for preprocessing, tuning, selection, or fitting. Prefixing the same rows with new names would defeat the check; IDs cannot establish independence by themselves.

heldout <- make_sample()
discovery_ids <- paste0("participant01:discovery:", seq_len(120))
confirmation_ids <- paste0("participant01:confirmation:", seq_len(120))
confirmation <- pattern_confirm(
  fit, heldout$X, heldout$Y,
  block_var = heldout$run,
  inference = confirmation_plan("sign_flip", n_resamples = 999, seed = 505),
  observation_ids = confirmation_ids,
  discovery_ids = discovery_ids,
  feature_ids = paste0("voxel", seq_len(p)),
  preprocessing_id = "simulated-BOLD-original-units-v1",
  subject_id = "participant01"
)
head(data.frame(feature = confirmation$feature_ids,
                F = confirmation$omnibus$F,
                p_max = confirmation$bootstrap$p_omnibus_max))
#>   feature        F p_max
#> 1  voxel1 34.01951 0.016
#> 2  voxel2 77.81606 0.004
#> 3  voxel3 48.09660 0.009
#> 4  voxel4 52.75659 0.007
#> 5  voxel5 23.07478 0.035
#> 6  voxel6 19.84900 0.049

Each row tests whether all frozen score coefficients at that feature are zero, conditional on any nuisance columns. Loadings and their standard errors are in original measurement units. All input features enter the hypothesis family, including ones screened or penalized to zero during discovery.

confirmation$estimate, $se, $t, and $p contain the component results. $p_holm adjusts over every feature-component pair. The omnibus table has its own Holm correction over features. Neither family correction simultaneously covers every alternative analysis a researcher might try.

plot(confirmation$omnibus$F, type = "h", xlab = "Input feature",
     ylab = "Omnibus Wald F")

Omnibus confirmation statistics across 32 simulated signal features.

Choose the error model before inspecting results

confirmation_plan("independent") uses ordinary Gaussian t/F tests with residual degrees of freedom. It assumes independent, homoskedastic rows.
confirmation_plan("block_robust") uses a CR1 sandwich and approximate t/Wald F inference with the number of independent blocks minus one as the denominator degrees of freedom. Few blocks can give unreliable inference. In the bundled 30-block null simulation, this approximation rejected 8.4% of nominal 5% omnibus tests; it should not be treated as exactly calibrated.
confirmation_plan("sign_flip", n_resamples = 999, seed = 1) refits restricted residuals using one Rademacher sign per independent block. This is an approximate restricted wild bootstrap, not an exact permutation test with estimated nuisance effects. $bootstrap$p_max maximizes across features within each component and Bonferroni-adjusts across components; $bootstrap$p_omnibus_max maximizes omnibus statistics across features. The same signs are used across features, preserving their joint dependence. The bundled null simulation rejected 4.1% of nominal 5% omnibus tests with 199 draws; this simulation is evidence for that design, not a guarantee for every block structure. Use more draws for final analysis.

The FSL randomise documentation also distinguishes exact exchangeability from approximate residual-based resampling with nuisance effects. No residual-resampling option repairs an incorrect independence or exchangeability assumption. A Monte Carlo p value cannot be smaller than 1 / (n_resamples + 1). For large feature families, Holm correction can therefore be unable to reject anything at the chosen resolution. Use the stated maximum-statistic family, or budget enough draws for the intended marginal-p correction; inspect Monte Carlo uncertainty near a decision threshold.

block_var identifies independent units; it does not add run intercepts. For that estimand, supply, for example, nuisance = model.matrix(~ factor(heldout$run))[, -1, drop = FALSE]. An intercept is always included. Redundant nuisance columns or target scores that cannot be distinguished from nuisance effects cause an error. Nonuniform row weights are unsupported. No p value is returned for a singular sampling distribution.

Separate association from incremental prediction

A decoded component can correlate with its target without improving prediction once other components are available. The two questions need different tests.

components <- pattern_component_tests(
  fit, confirmation, heldout$X, heldout$Y,
  calibration = list(dataset = discovery$X, design = discovery$Y,
                     observation_ids = discovery_ids)
)
components$association
#>   component correlation         t df     p p_holm
#> 1         1   0.9630855 31.035148 11 0.002  0.004
#> 2         2   0.5955507  7.525721 11 0.002  0.004
components$incremental
#>   component      gain         se        t df     p p_holm
#> 1         1 0.4515601 0.06245468 7.230206 11 0.001  0.002
#> 2         2 0.1883391 0.03514264 5.359275 11 0.001  0.002

Association is the partial correlation between each frozen decoded score and its corresponding target score, adjusting for the confirmation nuisance columns. It is marginal with respect to the other components.

For incremental value, full and reduced linear decoding heads are fitted on calibration rows only. Removing a component refits all remaining head coefficients. Both heads predict the untouched confirmation rows. Positive gain means that removing the component increases squared error. Loss is averaged over raw target columns, then within each block, then equally across blocks; choose commensurate target units before discovery. A paired block-mean t test provides approximate inference. For a sign-flip plan it is replaced by an approximate centered, studentized block wild bootstrap.

These comparisons evaluate the separately calibrated linear heads, not the original Gaussian posterior decoder. Categorical targets use one-hot squared loss, and linear head outputs are not probabilities. The confirmation object also includes descriptive held-out performance of the original decoder in $prediction.

Data and fit hashes prevent accidentally reusing a confirmation record with a different fit or different rows. Calibration IDs must belong to the declared discovery set and cannot overlap confirmation IDs. A completely untouched calibration split may be included in that declared set before confirmation.

Preserve the inferential record

saveRDS(list(confirmation = confirmation, components = components),
        "participant01-confirmation.rds")

The confirmation object retains the frozen raw target basis, coefficient covariance, preprocessing identifier and hash, observation IDs, block labels, and nuisance specification. Independent-error covariance is factorized into a small design covariance and per-feature residual variances. Block methods retain a small component-by-component covariance at each feature. Neither allocates a feature-by-feature covariance matrix.

Individual component effects depend on the frozen coordinates. Omnibus tests are invariant to nonsingular changes of score coordinates. Confirmation of several components is not a sequential rank test: rank_supported remains a separate research extension with a separately validated null.
