Contrasts, Inference, and Bootstraps • dkge

This vignette demonstrates how to generate subject-level contrasts using DKGE methodology, apply both analytic and bootstrap-based statistical inference procedures, and interpret the resulting outputs. We will walk through the complete workflow from contrast specification to statistical testing and visualization.

Demo Dataset

We begin by setting up a simulated dataset that illustrates the key components of a DKGE analysis. This synthetic dataset includes multiple subjects with different design matrices, beta coefficients, and spatial coordinates that will serve as the foundation for our contrast and inference examples.

library(dkge)
S <- 5; q <- 4; P <- 25; T <- 60
betas <- replicate(S, matrix(rnorm(q * P), q, P), simplify = FALSE)
designs <- replicate(S, {
  X <- matrix(rnorm(T * q), T, q)
  qr.Q(qr(X))
}, simplify = FALSE)
centroids <- replicate(S, matrix(runif(P * 3, -10, 10), P, 3), simplify = FALSE)
subjects <- lapply(seq_len(S), function(s) dkge_subject(betas[[s]], designs[[s]], id = paste0("sub", s)))
 bundle <- dkge_data(subjects)
fit <- dkge(bundle, K = diag(q), rank = 3)
fit$centroids <- centroids  # attach for transport helpers; pass explicitly in production

Leave-One-Subject-Out (LOSO) Contrasts

The LOSO approach provides an unbiased method for computing subject-level contrasts by using cross-validation. The dkge_loso_contrast() function computes these cross-validated subject contrasts while maintaining consistency of transport operators across all cross-validation folds, ensuring that spatial alignment remains stable throughout the procedure.

contrast_vec <- c(1, -1, 0, 0)  # effect1 minus effect2
loso <- dkge_contrast(fit, contrast_vec, method = "loso")

transported <- dkge_transport_contrasts_to_medoid(
  fit,
  loso,
  medoid = 1L,
  centroids = centroids,
  mapper = dkge_mapper("sinkhorn", epsilon = 0.05, lambda_xyz = 1)
)

str(loso$values, max.level = 1)
#> List of 1
#>  $ contrast1:List of 5

The resulting data structure contains several important components that capture different stages of the contrast computation process. The loso$values component stores the raw subject-level contrast vectors before any spatial transport has been applied. After transport to the medoid space, transported[[1]]$value contains the contrast values that have been aligned to the medoid parcellation and averaged across all subjects. Additionally, transported[[1]]$subj_values preserves the individual-subject contributions after transport, which can be useful for detecting outliers or understanding between-subject variability.

We can visualize the LOSO medoid map to quickly inspect the spatial pattern of contrast values.

loso_medoid <- transported[[1]]$value
plot(loso_medoid, type = "h", lwd = 2, main = "LOSO contrast on medoid clusters",
     xlab = "Medoid cluster", ylab = "Contrast value")
abline(h = 0, col = "grey60", lty = 2)

Lollipop plot of LOSO contrast values on medoid clusters.

Analytic Inference on Components

For statistical testing of group-level effects, we can apply analytic inference methods that leverage parametric assumptions about the underlying distributions. The dkge_component_stats() function combines subject loadings across the group, optionally performs sign-flip inference to handle arbitrary sign ambiguity in the components, and returns comprehensive summaries with false discovery rate (FDR) adjustments to control for multiple comparisons.

comp_stats <- dkge_component_stats(
  fit,
  components = 1:2,
  mapper = list(strategy = "sinkhorn", epsilon = 0.05, lambda_spa = 0.5),
  centroids = centroids,
  inference = list(type = "parametric"),
  medoid = 1L
)
#> Warning in mapply(FUN = f, ..., SIMPLIFY = FALSE): longer argument not a
#> multiple of length of shorter
head(comp_stats$summary)
#>   component cluster   stat     p p_adj significant
#> 1         1       1  1.279 0.270 0.480       FALSE
#> 2         1       2  1.175 0.305 0.480       FALSE
#> 3         2       1 -1.372 0.242 0.480       FALSE
#> 4         2       2 -0.941 0.400 0.480       FALSE
#> 5         1       1 -0.269 0.801 0.801       FALSE
#> 6         1       2 -1.112 0.328 0.480       FALSE

The resulting summary tibble provides a comprehensive overview of the statistical results, including component identifiers, cluster indices, test statistics, and both raw and FDR-adjusted p-values. This structured output enables systematic identification of clusters that surpass your predetermined significance threshold while accounting for multiple comparison corrections.

Bootstrap Inference

When the underlying effect distributions deviate substantially from Gaussian assumptions, or when sample sizes are small, bootstrap-based inference provides a more robust alternative to parametric methods. Both multiplier and resampling bootstrap approaches are available, and the analytic fit computed in the previous section can be efficiently re-used to seed the bootstrap resampling procedure, avoiding redundant computations.

subject_medoid <- lapply(seq_len(nrow(transported[[1]]$subj_values)), function(idx) {
  transported[[1]]$subj_values[idx, ]
})

boot <- dkge_bootstrap_projected(
  subject_medoid,
  B = 200,
  seed = 2
)

head(boot$medoid$mean)
#> [1]  0.137 -0.016 -0.012  0.110 -0.301  0.174

The dkge_bootstrap_projected() function returns comprehensive bootstrap statistics, including confidence intervals and standard errors, specifically computed for contrasts in the medoid space. For analyses that do not require spatial transport, you can alternatively use dkge_bootstrap_qspace() to work directly in the component basis, which bypasses the transport step and may be computationally more efficient for certain applications.

Practical Recommendations

When choosing between analytic and bootstrap inference methods, several considerations can guide your decision. Analytic inference provides computational efficiency and works reliably when you have moderate subject counts and when residual distributions appear approximately symmetric. However, bootstrap methods offer greater robustness to distributional assumptions, though they require more computational time. To mitigate the computational burden of bootstrap inference, the package leverages warm-started Sinkhorn transport algorithms and automatically caches dual variables to reduce runtime in subsequent iterations.

Regardless of the inference method chosen, it is essential to inspect the loso$values output to identify potential outlier subjects before reporting group-level results. This quality control step helps ensure that your conclusions are not unduly influenced by atypical individual responses and maintains the integrity of your statistical inferences.
