Representational Mapping (ReNA-Map): repmap_model

Source: vignettes/repmap_model.Rmd
repmap_model.Rmd

Overview

ReNA-Map estimates a low-rank linear map from seed feature vectors (one vector per item) to voxel patterns within an ROI/searchlight. It summarizes mapping rank, singular values, and in-sample variance explained (R²) per voxel.

  • Inputs: item key, seed feature matrix (rows = items), fMRI trials grouped by item
  • Output (per ROI): map_rank, map_sv1/mean, map_r2_mean/median, map_frob_norm
  • Implementation: reduced-rank regression (rrpack); falls back to zero map if rrpack is not installed, with a warning.

Scientific motivation

Many neuroscience questions ask: how is information from one domain (e.g., semantic features, visual properties, computational model states) encoded in neural activity?

Traditional encoding models use full-rank regression, which can overfit when features outnumber observations. ReNA-Map uses reduced-rank regression to:

  1. Discover the intrinsic dimensionality of the feature→brain mapping (via map_rank)
  2. Prevent overfitting by constraining the mapping to a low-dimensional subspace
  3. Identify dominant encoding axes (via singular values)

Example scientific questions: - How many independent dimensions of semantic space are encoded in anterior temporal cortex? - Does V1 use a low-rank mapping from Gabor filter banks (suggesting sparse coding)? - Which layers of a CNN best predict IT cortex, and how many principal components are needed?

Comparison to alternatives: - vs. Full regression: ReNA-Map regularizes via rank constraint rather than ridge/lasso penalties - vs. RSA: ReNA-Map models item-level patterns directly; RSA only models pairwise distances - vs. PLS/CCA: ReNA-Map explicitly estimates the coefficient matrix C for prediction; PLS focuses on latent variable correlation

When to use

  • You have model-derived features (e.g., CNN features, semantic embeddings, computational model states) for each stimulus item
  • You want to quantify how many dimensions of your feature space are encoded in a brain region
  • You need interpretable mapping coefficients (not just correlation strength)

Data requirements

  • A design with a per-trial item key used to average trials into item-level prototypes.
  • A seed feature matrix whose rownames match item IDs in the design.

Quick start: single ROI

The minimal path uses a small synthetic dataset and a single ROI built from a handful of voxels.

library(rMVPA)

## Synthetic dataset
ds  <- gen_sample_dataset(D = c(6,6,6), nobs = 60, response_type = "categorical",
                          data_mode = "image", blocks = 3, nlevels = 6)

## Add an item identity column to group trials into item prototypes
K <- 6
items <- paste0("I", 1:K)
ds$design$train_design$ImageID <- factor(rep(items, length.out = nrow(ds$design$train_design)), levels = items)

## Seed features (K x P) labeled by item
P <- 8
seedF <- matrix(rnorm(K * P), K, P)
rownames(seedF) <- items

## Build design helper and model spec
rpdes <- repmap_design(items = items, seed_features = seedF)
rpmod <- repmap_model(dataset = ds$dataset, design = ds$design,
                      repmap_des = rpdes, key_var = ~ ImageID,
                      rank = "auto", max_rank = 5)

## Define a small ROI (50 voxels)
vox <- which(ds$dataset$mask > 0)[1:50]
roi <- list(train_roi = neuroim2::series_roi(ds$dataset$train_data, vox), test_roi = NULL)

## Per-ROI processing
out <- process_roi(rpmod, roi, rnum = 1)
out$performance[[1]]

Regional analysis (run_regional)

The same model can be applied across labeled regions. The example below builds a simple two-ROI mask for demonstration. This step can take longer; we keep it disabled by default.

## Create a toy two-ROI mask by splitting the active mask indices
## (This is just to illustrate the API; use real ROI atlases in practice.)
region_vec <- as.vector(ds$dataset$mask)
inds <- which(region_vec > 0)
half <- length(inds) %/% 2
region_vec[inds[1:half]] <- 1L
region_vec[inds[(half+1):length(inds)]] <- 2L
region_vec[region_vec <= 0] <- 0L
region_mask <- neuroim2::NeuroVol(array(region_vec, dim = dim(ds$dataset$mask)), neuroim2::space(ds$dataset$mask))

## Run per-ROI mapping (disabled by default to keep vignette fast)
# res <- run_regional(rpmod, region_mask)
# head(res$performance_table)

Interpreting outputs

  • map_rank: estimated rank (auto via CV or fixed).
  • map_sv1 / map_sv_mean: largest and mean singular values (mapping strength diagnostics).
  • map_r2_mean / map_r2_median: average/median in-sample variance explained across voxels.
  • map_frob_norm: Frobenius norm of the mapping matrix.

Notes and pitfalls

  • Centering: X and Y are column-centered before fitting; this is standard for RRR.
  • Negative R² can occur when the mapping underperforms the mean model; treat as a diagnostic rather than an error.
  • Item alignment: items are intersected and sorted across design, ROI and seed features; mismatched labels reduce K.
  • Small K: results are flagged as potentially unstable when K < 5.
  • rrpack missing: the method returns a zero map (rank=0) and logs a warning.
