Introduction

Standard Representational Similarity Analysis (RSA) asks whether a brain region’s representational geometry matches a predicted similarity structure, typically returning a single correlation value. While powerful, this approach cannot tell you which aspects of the representational structure drive the effect, or which individual voxels contribute most to specific theoretical dimensions.

contrast_rsa_model() implements the Multi‑Dimensional Signed Representational Voxel Encoding (MS‑ReVE) approach to address these limitations. MS‑ReVE decomposes the local representational geometry into user-defined contrasts—linear combinations of experimental conditions that capture theoretically meaningful dimensions. For example, in a study with four object categories, you might define contrasts for “animate vs. inanimate” and “biological vs. mechanical” to test whether these conceptual dimensions are spatially dissociable.

The method produces signed voxel-wise maps showing how strongly each voxel supports or opposes each contrast. Positive values indicate a voxel’s pattern aligns with the predicted contrast direction; negative values indicate opposition. This signed, contrast-specific information enables more mechanistic interpretations than standard RSA’s omnibus similarity measure.

This vignette walks through a compact example and explains the output metrics.

Example setup

We start by generating a small dataset and defining two contrasts. Contrasts should be column‑centered: positive values indicate conditions that pull voxel patterns in one direction, negatives in the opposite direction.

# Generate dummy dataset (small 6x6x6 volume, 32 samples)
set.seed(42)
data_info <- gen_sample_dataset(D = c(6,6,6), nobs = 32, blocks = 4)

# mvpa_dataset object
mvpa_dat <- data_info$dataset

# Define two contrasts across four conditions
# Each row = condition, each column = contrast
K <- nresponses(data_info$design)
condition_labels <- levels(data_info$design$y_train)

C_mat <- matrix(0, nrow = K, ncol = 2)
rownames(C_mat) <- condition_labels

# Contrast 1: conditions {1,2} vs {3,4}
C_mat[1:2, 1] <- 1
C_mat[3:4, 1] <- -1

# Contrast 2: condition 1 vs condition 2
C_mat[1, 2] <- 1
C_mat[2, 2] <- -1

# Center each contrast (required for proper interpretation)
C_mat <- base::scale(C_mat, center = TRUE, scale = FALSE)
colnames(C_mat) <- c("AB_vs_CD", "A_vs_B")

# Visualize the contrast matrix
print("Contrast Matrix (centered):")
## [1] "Contrast Matrix (centered):"
print(round(C_mat, 2))
##   AB_vs_CD A_vs_B
## a        1      1
## b        1     -1
## c       -1      0
## d       -1      0
## e        0      0
## attr(,"scaled:center")
## [1] 0 0
ms_des <- msreve_design(data_info$design, contrast_matrix = C_mat)

Next we create the model specification and run a tiny searchlight over the volume, requesting the default "beta_delta" metric.

cv_spec <- blocked_cross_validation(data_info$design$block_var)

model_spec <- contrast_rsa_model(
  dataset = mvpa_dat,
  design = ms_des,
  output_metric = "beta_delta",
  check_collinearity = FALSE,
  cv_spec = cv_spec
)

# Run a very small searchlight iterator
slight <- get_searchlight(model_spec$dataset, type = "standard", radius = 2)
center_indices <- which(model_spec$dataset$mask > 0)
iter_res <- mvpa_iterate(model_spec, slight, center_indices, analysis_type = "searchlight")

# Inspect the beta_delta metric for the first few centers
preview_ids <- seq_len(min(5, length(iter_res$performance)))
preview_rows <- lapply(preview_ids, function(idx) {
  perf_i <- iter_res$performance[[idx]]
  vals <- if (is.list(perf_i) && !is.null(perf_i$beta_delta)) {
    perf_i$beta_delta
  } else {
    perf_i
  }

  if (is.null(vals)) {
    return(NULL)
  }
  if (is.null(names(vals)) || !any(nzchar(names(vals)))) {
    names(vals) <- paste0("contrast_", seq_along(vals))
  }

  data.frame(
    center_id = iter_res$id[idx],
    contrast = names(vals),
    beta_delta = as.numeric(vals),
    row.names = NULL
  )
})
preview_rows <- Filter(Negate(is.null), preview_rows)
preview_tbl <- if (length(preview_rows) == 0) data.frame() else do.call(rbind, preview_rows)
preview_tbl
##    center_id            contrast   beta_delta
## 1          1 beta_delta.AB_vs_CD -0.024391747
## 2          1   beta_delta.A_vs_B -0.026302164
## 3          2 beta_delta.AB_vs_CD -0.261628397
## 4          2   beta_delta.A_vs_B -0.006443043
## 5          3 beta_delta.AB_vs_CD -0.258305514
## 6          3   beta_delta.A_vs_B  0.206626529
## 7          4 beta_delta.AB_vs_CD -0.091095103
## 8          4   beta_delta.A_vs_B -0.090866802
## 9          5 beta_delta.AB_vs_CD -0.039160407
## 10         5   beta_delta.A_vs_B -0.336847744

Understanding the metrics

contrast_rsa_model can return several metrics. Multiple metrics can be requested at once and are returned in a named list for each searchlight location.

Each metric combines two key quantities in different ways:

  • β_q: The RSA regression coefficient showing how much contrast q explains the local representational dissimilarity matrix (RDM)
  • Δ_{q,v}: The projection of voxel v’s pattern onto contrast q, indicating directional alignment

The main output options are:

beta_delta

The product of the RSA regression coefficient (βq\beta_q) and the voxel’s projection onto each contrast (Δq,v\Delta_{q,v}). This signed quantity indicates how strongly the voxel supports the representational difference captured by each contrast. Positive values mean the voxel pattern aligns with the predicted direction; negative values indicate the opposite.

beta_only

Only the regression coefficients βq\beta_q. Useful when you want a map of how much each contrast explains the local RDM independent of the voxel projections.

delta_only

The projection values Δq,v\Delta_{q,v} by themselves. These show the raw contribution of each voxel to the contrast space before weighting by βq\beta_q.

recon_score

A single value (per voxel) measuring how well the voxel’s beta-weighted pattern reconstructs the empirical RDM of the searchlight. Higher values indicate the voxel is individually informative about the multi-contrast representational structure.

beta_delta_norm

Like beta_delta but using an L2-normalized contribution vector. This emphasizes the direction of the contribution rather than its magnitude and requires normalize_delta = TRUE when constructing the model.

beta_delta_reliable

Reliability-weighted contributions ρq,vβqΔq,v\rho_{q,v} \beta_q \Delta_{q,v}. The weights ρq,v\rho_{q,v} reflect how stable each voxel’s contributions are across cross-validation folds, highlighting consistent effects.

composite

The sum of beta-weighted, normalized contributions across contrasts (∑qβqΔ̃q,v\sum_q \beta_q \tilde{\Delta}_{q,v}). This “net pull” summarizes whether a voxel overall favors the positive or negative side of the contrast space. Interpretation is easiest when the contrast matrix is orthonormal.

Together these metrics support flexible interrogation of how each voxel or region participates in the specified representational contrasts.

Conclusion

contrast_rsa_model extends standard RSA by decomposing voxel contributions along user-defined contrasts. By selecting appropriate output metrics you can visualize beta weights, raw contributions, reliability-weighted effects, or overall reconstruction quality. The combination of metrics provides a rich picture of the representational landscape revealed by the analysis.

When to use MS-ReVE

Use MS-ReVE when you have:

  • Theory-driven predictions about which representational dimensions matter (e.g., semantic features, perceptual attributes)
  • Multiple contrasts you want to test simultaneously and spatially dissociate
  • Interest in signed contributions: not just whether a region represents a distinction, but which voxels favor which direction

Use standard RSA when you have a full predicted RDM but no specific contrast structure, or when you want an omnibus test of representational similarity.

Important considerations

  • Contrast centering: Contrasts must be column-centered (zero mean) for proper interpretation
  • Cross-validation: Required to obtain unbiased condition estimates; bootstrap resampling is not supported
  • Orthogonality: The composite metric requires orthonormal contrasts; otherwise interpretation is ambiguous
  • Block structure: Use keep_intra_run = FALSE to exclude within-run comparisons if temporal autocorrelation is a concern
