Print and Plot for sampling_frame

Custom print and plot methods for sampling_frame objects (from fmrihrf). The print method provides a concise summary focused on runs/blocks, TR and total scans without mentioning lower-level evaluation precision. The plot method visualizes runs over time.

Usage

# S3 method for class 'sampling_frame'
print(x, ...)

# S3 method for class 'sampling_frame'
plot(x, style = c("timeline", "grid"), show_ticks = FALSE, tick_every = 5, ...)

Arguments

x

A sampling_frame object created by fmrihrf::sampling_frame().

...

Unused.

style

Plot style for plot(). One of "timeline" (default) or "grid". "timeline" draws a horizontal bar per run; "grid" shows a scan grid by run.

show_ticks

Logical; for plot(), whether to show per-TR tick marks along each run (timeline style only). Default FALSE.

tick_every

Integer; draw a tick every tick_every TRs when show_ticks = TRUE. Default 5.

Value

For print(), returns x invisibly. For plot(), a ggplot object.

Examples

sf <- fmrihrf::sampling_frame(blocklens = c(60, 120), TR = 2)
print(sf)
#> Sampling frame
#> - Blocks: 2
#> - Scans: 180 (per block: 60, 120 )
#> - TR: 2 s
#> - Duration: 359 s
plot(sf)
#> Warning: ‘-’ not meaningful for factors
#> Warning: reverse transformation introduced infinite values.
#> Warning: ‘-’ not meaningful for factors
#> Warning: reverse transformation introduced infinite values.
#> Warning: Position guide is perpendicular to the intended axis.
#> ℹ Did you mean to specify a different guide `position`?
#> Warning: Removed 2 rows containing missing values or values outside the scale range
#> (`geom_segment()`).
